Steinmeyer, Inc

A new miniature ball screw line called optiSLITE has been introduced by Steinmeyer. Featuring low friction torque that delivers smoother running and enables greater accuracy, these screws also provide a result that is a superior positioning performance in semiconductor, optics, medical instrument, and metrology applications.

Specifically engineered for the low duty cycle applications of linear actuators, the new ball screw line from Steinmeyer reaches high thrust requirements and also offers long service life, low maintenance and reliability.

Featuring a compact design with a height of only 50mm and length and width of 210mm, the KT210-EDLM precision linear stage system has been released by Steinmeyer. Travel is 100x100mm and includes custom designed low profile direct drive ironless linear motors.

Steinmeyer today announced that it has redesigned its corporate home page. The site now allows users to be able to navigate more easily and efficiently to any of the three core competence centers that make up the Steinmeyer group, which are ball screws, precision stages and metrology products.

Steinmeyer today announced a new addition to its line of precision rotary stages. The DT240 stage is driven by a torque motor for high speed motion. With an overall height of 100 mm and width of 240 mm this stage is ideal for applications requiring space saving solutions.

Steinmeyer announced today a new design to the ball return for its UltraSpeed line of precision ball screws. This new design is based on a new ball return system that uses precision ball deflectors to guide the balls into a return channel spanning the whole nut length. The deflectors are precision milled and utilize a complex geometry that minimizes friction thus allowing higher speeds with less wear and better smoothness.

Steinmeyer announced an important addition to its standard line of miniature precision screws – the world's smallest commercially available ball screw. New ULTRAMINIATURE ball screws are available in diameters as small as 3 millimeter with choice of two pitches – 1 millimeter or 0,5 millimeter, making this product ideal for medical applications, such as precise liquid dispensing, among others.

Steinmeyer, Inc. announced an exciting new addition to its line of precision linear stages. Our model PMT320 offers a repeatability of +/- 1 micron, excellent straightness run-out accuracy and travel distances from 600 to 1500 mm. The stage has a 320 mm wide die cast base profile and the 1000 mm stroke stage weighs 70 kg.

Steinmeyer, Inc. announced a brand new product focusing on the miniature robotics and life sciences markets: a new integrated miniature actuator consisting of a small DC servomotor coupled to a precision ball screw. Due to its compact design, no external bearing and coupling are required!

Steinmeyer, Inc. announced a new high precision, light weight, micro manipulator stage MT 105-50-LM. This stage is an excellent choice for applications in the semiconductor metrology, biomedical, miniature robotics and laser industry.

Steinmeyer, Inc. offers custom motion systems for the life sciences market. Typical applications include cell inspection, resonance scanners, computer tomography and precision dispensing systems. These high precision systems are specifically designed to fit customer requirements for accuracy, repeatability, environment, load capacity and space constraints. By offering cost effective custom solutions, Steinmeyer is able to provide exactly what customers require and desire versus something close that may be in a catalog.

Steinmeyer, Inc. announced a new addition to its extensive line of precision ball screws – a 28 mm diameter screw with 12 mm pitch. Normally our product line is guided by the DIN standard which specifies shaft diameters of 20, 25, 32, 40 mm, etc. This new 28 mm diameter product was designed as a size compatible with the JIS standard. The ball screw is supplied with choice of two nut styles: single nut with flange series 1416; or double nut with flange series 1516. The ball nut is normally provided preloaded for zero backlash. The screw shaft is precision ground and offered in accuracy grades T0 to T5. Threaded length, journal details and overall length are per customer specification.

Steinmeyer, Inc. announced a brand new product focusing on the miniature robotics and life sciences markets: a new integrated miniature actuator consisting of a small dc servomotor coupled to a precision ball screw. Due to its compact design, no external bearing and coupling are required! Included in the completely integrated assembly is a high precision Steinmeyer miniature 8 mm diameter ball screw, a Faulhaber DC motor with graphite commutation, rotary encoder and gearless coupling. The result is high speed, backlash free positioning with high dynamic performance. Typical applications include miniature robotics and precision dispensing systems.

Steinmeyer, Inc. announced a new precision, multi- axis air bearing gantry system. This motion system consists of an XY stage utilizing air bearings plus a conventional ball screw driven Z table. It is ideal wherever there is a need for ultra high precision and outstanding dynamic performance.

Steinmeyer, Inc. has announced a new product to its extensive line of miniature ball screws. These 5mm diameter screws are the perfect solution in applications such as micromanipulators, miniature robotics and compact actuators.

Steinmeyer, Inc. announced a new multi-axis modular assembly designed specifically for 3D target positioning and alignment. Typical applications include R&D and scientific uses such as synchrotrons. For example, the new system is ideal for beam positioning and sample manipulation.

Steinmeyer, Inc. announced a new product the LT490-450-EDLM! This 2 axis system is ideal for laser machining as well as other extended travel applications where precision positioning is critical. It’s a fully enclosed 2 axis stage with 450 mm stroke. Included inside this precision assembly are iron-core linear motors, linear guideways, linear measuring system and E chain cable carriers. Maximum speed is 500 mm/s with acceleration of 5 m/s². Accuracy in each direction is 1 micron with ± 0.5 micron repeatability.

Steinmeyer, Inc. announced the MP63 3 axis micro manipulator module, a fully enclosed 3 axis positioner with 25 mm stroke in each direction. Included inside the compact precision assembly are dc gear motors, rotary encoders, lead screws, and non-contact limit switches. Accuracy in each direction is 5 microns with ± 1 micron repeatability.

Steinmeyer Inc. announced a new, more enhanced web site for its high precision positioning stages. The web site, located at www.feinmess.de, details motion solutions – from an extensive portfolio of standard positioning stages to more complex customized systems. Included are linear stages (single and multi-axis), rotary stages, goniometers, lift tables and motion controllers.

Steinmeyer, Inc. announced an exciting new addition to its line of precision linear stages. Manufactured by our FMD division, Dresden Germany, the model PMT320 offers a repeatability of +/- 1 micron, excellent straightness run-out accuracy and travel distances from 600 to 1500 mm. The stage has a 320 mm wide die cast base profile and the 1000 mm stroke stage weighs 70 kg.
