XY stage with internal motor & controller

Featuring a compact design with a height of only 50mm and length and width of 210mm, the KT210-EDLM precision linear stage system has been released by Steinmeyer. Travel is 100x100mm and includes custom designed low profile direct drive ironless linear motors.

A key feature of this stage is that all motors, cable carriers and controller are integrated inside the unit, making it suitable for space saving motion applications. Additionally, due to the integrated controller, all electronics including motor drives are packaged completely inside; communication is simple though a universal USB interface. The KT210-EDLM is suitable for life science, semiconductor, fibre optics and micro-manufacturing applications.
