UHF read/write heads from Pepperl+Fuchs function reliably even under harsh ambient conditions, while still offering a high level of flexibility.The F190 UHF read/write head has been a hit on the market for two years now. The device is designed to be the ideal solution to potentially problematic applications where the installation space is limited and for which read distances of 1 m to 2 m are sufficient. It is precisely these functions that are increasingly in demand within the framework of Industry 4.0—a development stage that requires identification as early as during production processes and not after products have been completed in the subsequent logistics chain, as was the case previously.

The UMB800 from Pepperl+Fucs is the world's smallest ultrasonic sensor in solid stainless steel. It is made entirely from FDA-compliant materials. With its large detection range and highly compact design, it opens up new automation possibilities in hygienic applications.

The UMB800 from Pepperl+Fuchs is the world's smallest ultrasonic sensor in solid stainless steel. It is made entirely from FDA-compliant materials. With its large detection range and highly compact design, it opens up new automation possibilities in hygienic applications.The new sensors in the UMB800 series feature hygienic housing that is made entirely from V4A stainless steel. The surface roughness of the housing is less than 0.8µm, minimizing the risk of microbial contamination. The outer skin is hermetically sealed and free from gaps. The sensor can withstand steam jet treatment and aggressive cleaning agents. It features IP68/IP69K degrees of protection and ECOLAB certification. No cleaning processes need to be changed when the sensor is installed in existing systems.

Pepperl+Fuchs has acquired MACTek Corporation, a leading provider of HART protocol devices. The move is part of Pepperl+Fuch’s strategy to further extend its integrated solutions offerings and strengthen its position in the WirelessHART market.

Pepperl+Fuchs is setting a new and innovative standard for AS-Interface IP20 modules in the form of an easily accessible push-in connection at the front of the device. The crimped wire ends can be inserted directly into the push-in terminals. The entire wiring harness is guided downward, meaning there is no need for the upper cable ridge/cable duct. This not only provides a sophisticated solution for the switch cabinet wiring, but also saves on space and ensures clarity. In switch boxes, modules featuring this connection can be mounted flush on the upper edge of a switch box, without impairing the installation. The transparent hinged cover, which can be snapped into place at multiple points, ensures a clear view through to the digit display at all times and enables the terminal functions to be color-coded internally. The terminals can be removed individually and are coded to prevent them from being mixed up, meaning devices can be replaced without any problems.

Taking full advantage of Pepperl+Fuchs' powerful Pulse Ranging Technology (PRT), the R2000 Detection scanner is the ideal solution for demanding field monitoring applications and assistance systems. Empty bay detection and gap recognition are as easily accomplished as the detection of overhanging and interfering products in high-speed AS/RS applications. Assistance systems for collision avoidance in both automatic guided vehicles or manually controlled forklifts and tuggers are another class of applications where the PRT-enabled R2000 Detection offers outstanding features and performance.

Pepperl+Fuchs introduces ENA58IL and ENA36IL magnetic absolute rotary encoders. These next-generation encoders combine precision and high-speed resolution in a compact design. They are packed with features and options that maximize process reliability, efficiency and service life ideal for a wide range of OEM and plant automation applications.

Pepperl+Fuchs introduces the R2000 Detection Laser Scanner. Smaller than most coffee mugs, these 2D laser scanners feature a 360-degree gapless measurement angle with angular resolution within 0.071 degrees, scan frequency to 30 Hz and object detection down to 1 mm. An eye-safe visible red laser simplifies alignment and, because the light spot is up to 15 times smaller than competitive technology, it enables precise detection of very small objects or reflectors. R2000 Detection Scanners can also detect objects up to 10 m away and reflectors up to 30 m away, with measurement repeatability that is always within 12 mm of true distance value. A 360 degree LED display provides quick visual status indication.

Pepperl+Fuchs introduces the new compact F190 UHF Read/Write Head. The F190 features a robust sealed metal housing and a compact footprint for reliable operation in adverse environmental conditions and simple installation even in tight spaces. Because several products in a container can be detected at the same time using multi-tag reading, the F190 simultaneously simplifies processes and reduces processing time. The F190 easily integrates into existing IDENTControl systems, enabling users to connect to standard protocols such as Ethernet/IP, PROFINET, TCP/IP and EtherCAT. Three reader versions are available to cover worldwide operation.

Vision Sensors today can be highly sophisticated systems, as illustrated by the new OPC 120 Series code reader for 1-D and 2-D codes. In addition to its functionality, compact design, and high speed, the special features of this device include a polarization filter for reading high-gloss materials and a PROFINET connection.Image: OPC120P—reliable reading on reflective surfaces

A range of purge solutions, the Bebco EPS line from Pepperl+Fuchs, has been expanded with the introduction of the 5500 system. The Type Z / Ex pz purge system delivers a fully automatic solution in a compact, 316L stainless steel design. Combined with global certifications, menu-driven programming, and automatic leakage / temperature compensation, the 5500 is the all-in-one solution for Div. 2 / Zone 2 applications.

A compact cold store scanner has been introduced by Pepperl+Fuchs, addressing the difficult ambient conditions which exist during the processing, transportation, and identification of products. The VB14N-T scanner operates at temperatures from -35°C to +45°C and, with a scan rate of up to 1000 scans/s and resolutions of 0.2 mm, delivers the same performance as the VB14N type counterpart for standard temperatures.

A vision sensor, featuring a polarisation filter for reading high-gloss materials and a PROFINET connection, has been launched by Pepperl+Fuchs. The OPC120 Series code readers offers stationary readers for detecting and decoding 1-D and 2-D codes, such as barcodes and Data Matrix codes. The housing may only be 70 x 70 x 54mm, but the device contains a CMOS imager, an LED flash, and a control interface.

The robust yet accurate measuring method makes ultrasonic sensors ideal for a wide variety of applications. Simple parameterization - if the application requires it - coupled with measuring ranges extending from a few centimeters to 10 m turn ultrasonic sensors from problem solvers into sensors for every application.

Absolute rotary encoders with magnetic detection principle from Pepperl+Fuchs combine compact designs, robustness, and service life with high resolution and accuracy, and in so doing open up new fields of application. Singleturn absolute rotary encoders from Pepperl+Fuchs are based on two-axis Hall sensors. These encoders can be turned into multiturn absolute rotary encoders through the addition of a Wiegand sensor.

Pushing the limits of physical possibility is the greatest challenge facing technology. In addition to technical excellence, the economic aspect is taking on an increasingly important role. The machine construction market is continuously aiming for more compact, faster machines with higher capacity. Special packaging machines or machines for manufacturing PCBs are being constantly optimized to enhance their overall power density. In addition to mechanical components, electronic components that control the systems must also be consistently adapted.

AS-Interface is the world´s most widely-used interface concept, which has simplified automation through quick connection technology via flat cables. The integration of safety on AS-i was a further important step towards an end-to-end solution which set new standards in terms of simplicity, clear overview and cost-efficiency.

Not all time-of-flight measurements are the same. On the basis of pulse ranging technology (PRT) developed by Pepperl+Fuchs, a new, innovative laser scanner has been produced that impressively demonstrates the advantages of this technology. To this end, further highly interesting innovations have been incorporated in the development of this device in addition to the use of PRT.

Whether path correction, edge or gap measurement, volume measurement or tolerance verification, the tasks and requirements of modern vision solutions are varied. Pepperl+Fuchs has developed a powerful and reliable laser light sensor in the form of the LineRunner 300 (LR300) to overcome these challenges.

Many process automation applications require versatile devices. The new signal conditioner KFU8-VCR-1 from Pepperl+Fuchs combines a universal power supply for 2- and 3-wire transmitters with signal converter functionality. Multiple outputs offer active and passive current sources and one voltage output, allowing a flexible adaptation of the field signal to the control system.
