A premier platform for Supervisory Control and Data Acquisition (SCADA), Building Management Systems (BMS) and Human-Machine Interface (HMI) solutions has been released by ARC Informatique. BACnet Testing Laboratories has awarded PcVue 11.2 its highest level listing, BACnet Advanced Work Station (B-AWS).

The building´s owner SFL (Lyon Property Company) undertook extensive renovation, especially for office accommodation. An efficient BMS was needed to enable the company to operate and monitor the 37,000m2 of available floor space. In particular, this had to be managed and optimized to allow energy consumption to be reduced by 20% to 30%.

This trend-setting building comprises a clinic for physiotherapy and medical muscle-building plus the officesof the builder, Steffen Holzbau. All of the efficiency systems are monitored from a PcVue 9.0 BMS systemwith remote WebVue access linked to BACnet controllers and communication. As a specialist in design of wooden buildings, Steffen Holzbau planned and built the facility in cooperation with Sanichaufer based in Luxembourg - where the building is situated - and the contractor GIGAAutomation of Saarbrücken in Germany. GIGA-Automation is a PcVue Solutions Certified Partner which provides integrated building management systems (IBMS) in Germany and Luxembourg. The BACnet network was developed to rigorous specifications: PcVue for the operator workstation and control system, DDCs from SAIA Burgess with native BACnet communication and a Menerga Control System for the swimming pool and therapy controls.

Iberdrola Renewables, the second-largest energy provider in North America has chosen PC VUE SCADA system to monitor it´s US wind farms, producing 3,600 megawatts of wind power over 35 independent power plants. Each of the 2479 wind turbine supplies about 300 to 350 data points, which equates to approximately 700,000 to 850,000 I/O data points on nearly two dozen servers.

Systems integrator ETDE has chosen PcVue 9.0 from ARC Informatique to monitor the electricity distribution and air conditioning systems for the entire range of installations at TelecityGroup´s new Data Centre in the Paris region. The software´s openness and the simple hierarchy used for the communication architecture were determining factors in this choice. PcVue can, as part of its functions, generate reports on the electricity consumption by each of the servers operated by TelecityGroup´s customers.

The SECHE Group and its subsidiary TREDI have chosen ARC Informatique´s PcVue to set the future standard for its plants, including household and industrial waste incineration plants, and biogas power plants. Since its first deployment in 2005, it can now be found in 16 plants and workshops, representing more than 500,000 variables being processed, applied and logged by PcVue.

The new version of the PcVue software edited by ARC Informatique puts the accent on opening up links to new protocols, such as integration of OPC KEPWARE servers and Smart Generator Step7®. Version 9.0 features major innovations that help to cut deployment and operating costs even further for process monitoring projects and utilities.
